Refrigerant Pipe Insulation Thickness Calculation

New pipe insulation thicknesses.

Refrigerant pipe insulation thickness calculation.

Thermal conductivity of the insulation material for the temperature range of the pipe can be taken as 0 04 w m k. Overall this is good news giving mechanical insulation an opportunity to contribute to. 1 inch 25 4 mm insulation of a cold systems should be made with micro cellular cross linked polyethylene foam with low water vapor diffusion. Pipe insulation thicknesses are greater than or equal to those in the 2007 standard but duct insulation thicknesses have not changed.

What are the new pipe and duct insulation thickness requirements in standard 90 1 2010. The pipe size is 8 and the maximum allowable temperature of outer wall of insulation is 50 0 c. Hot cold water freeze protection. Hence insulation thickness ri rp 0 2302 0 1524 0 0777 insulation thickness 77 7 mm extra margin must be taken on insulation thickness as sometimes conducting heat transfer through insulation may become higher than convective heat transfer due to air on outside wall of insulation.

There is usually no additional benefit of adding more than 1 2 thick fiberglass or rubber pipe insulation to cold water piping. One vrf manufacture may require 1 1 2 and another 2 1 2 of insulation for the high pressure vapor piping. Calculate insulation thickness minimum value required for a pipe carrying steam at 180 0 c. You can see that knowing the vrf vrv manufactures requirement for the temperature rating of the insulation can have an effect on the thickness of the insulation required for the same size of pipe in the system.
